Product Details
| Type | Max capacity | S-cam、Brake | Track | brake chamber distance | axle beam | wheel fixing | Wheel base | Recommended wheel | Weight | Bearing | |
| Φ × width | SP | GM | □ | stub | P.C.D | WB | |||||
| kg | mm | mm | mm | mm | mm | mm | kg | ||||
| HS24DXA2-00 | 24,000 | S 420 ×200 | 1840 | 354 | □150 | 10*M22*1.5 ISO | 335 | 1400 | 7.50v-20 | ≈1950 | 33213 /33118 |
| HS28DXA2-00 | 28,000 | S 420×200 | 1840 | 354 | □150 | 10*M22*1.5 ISO | 335 | 1550 | 8.00v-20 | ≈2400 | 33215 /32219 |
| HS32DXA2-00 | 32,000 | S 420×200 | 1850 | 356 | □150 | 10*M22*1.5 ISO | 335 | 1550 | 8.00v-20 | ≈2500 | 32222 /32314 |
